AFOX Graphic Card GeForce GTX 750 Ti 4GB GDDR5

Features

AFOX GeForce GTX 750 Ti 4GB GDDR5 graphics card is based on the GeForce GTX 750 Ti graphics chip with NVIDIA Maxwell architecture. The core clock is 1020 MHz, while a PCI Express 3.0 interface is used for system connectivity.

The graphics card has 4 GB of video memory. It uses GDDR5 memory operating at 5400 MHz with a 128-bit memory bus.

NVIDIA GPU Boost support allows the graphics processor to dynamically adjust its operating frequency depending on the workload. NVIDIA Adaptive V-Sync is designed to synchronize the frame output rate with the display refresh rate and reduce screen tearing.

NVIDIA PhysX provides support for hardware-accelerated physics effects in compatible software, while NVIDIA 3D Vision is designed for use with compatible stereoscopic 3D content. The graphics card also supports DirectX 11 and OpenGL 4.5 graphics APIs.

DVI, HDMI, and D-Sub (VGA) outputs are provided for connecting display devices. The maximum supported resolution is 2560 × 1600. The active cooling system includes a heatsink and two fans, the graphics card occupies two slots, and no additional power is required.

Technologies (Used)

• NVIDIA Maxwell architecture
• NVIDIA GPU Boost
• NVIDIA Adaptive V-Sync
• NVIDIA PhysX
• NVIDIA 3D Vision
• DirectX 11
• OpenGL 4.5
• 4 GB GDDR5 memory
• 128-bit memory bus
• PCI Express 3.0 interface
• Active cooling system
• Heatsink and two fans
• DVI, HDMI, and D-Sub (VGA) video outputs
• Resolution support up to 2560 × 1600
• No additional power required

Technical Specifications

• Brand: AFOX
• Article: AF750TI-4096D5H1-V2
• Graphics chip: GeForce GTX 750 Ti
• Architecture: NVIDIA Maxwell
• Core clock: 1020 MHz
• Memory type: GDDR5
• Memory capacity: 4 GB
• Memory clock: 5400 MHz
• Memory bus width: 128-bit
• Interface: PCI Express 3.0
• Form factor: Standard
• Cooling system: 2 fans + heatsink
• Video outputs: DVI, HDMI, D-Sub (VGA)
• Maximum supported resolution: 2560 × 1600
• Supported 3D APIs: DirectX 11, OpenGL 4.5
• Additional power: None
• Cooling type: Active
• Slots occupied: 2

For Whom

• For systems compatible with PCI Express 3.0 graphics cards
• For configurations requiring DVI, HDMI, or D-Sub (VGA) video outputs
• For use with compatible software supporting DirectX 11 or OpenGL 4.5
• For systems requiring a graphics card without additional power
• For configurations that support a dual-slot graphics card

Conclusion

AFOX GeForce GTX 750 Ti 4GB GDDR5 graphics card combines a GeForce GTX 750 Ti graphics chip based on the NVIDIA Maxwell architecture with 4 GB of GDDR5 memory and a 128-bit memory bus. The model supports NVIDIA GPU Boost, Adaptive V-Sync, PhysX, 3D Vision, DirectX 11, and OpenGL 4.5. DVI, HDMI, and D-Sub (VGA) outputs are provided for connecting displays, while the active cooling system consists of a heatsink and two fans.
