Access Point MikroTik wAP ax LTE7 kit (wAPGR-5HaxD2HaxD&R11e-LTE7)

Features

The MikroTik wAP ax LTE7 kit is designed for wireless connectivity in locations where wired internet access is unavailable or requires backup support. The device combines an LTE Category 7 modem with Wi-Fi 6 technology for stable indoor and outdoor networking scenarios.

LTE carrier aggregation improves data throughput and connection responsiveness in congested mobile networks. The unit supports LTE FDD and TDD bands and uses a Micro SIM slot for mobile connectivity.

Dual-band Wi-Fi 6 delivers wireless speeds up to 574 Mbps on 2.4 GHz and up to 1200 Mbps on 5 GHz. Integrated antennas with 6.9 dBi and 7 dBi gain help maintain stable coverage across surrounding areas.

The IP66-rated enclosure is built for outdoor deployment and operation in temperatures from -30 °C to +70 °C. Power can be supplied through 802.3af/at PoE-in or a 12-57 V DC input for flexible installation options.

Technologies (used)

• Wi-Fi 6
• LTE Category 7
• Carrier Aggregation
• RouterOS v7
• PoE-in 802.3af/at
• MIMO 2x2
• Dual-band Wi-Fi
• IP66

Technical specifications

• Processor IPQ-5010
• 2 cores, 800 MHz
• ARM 64bit architecture
• RouterOS v7
• 256 MB RAM
• 128 MB NAND storage
• LTE Cat 7 up to 300 Mbps DL and 100 Mbps UL
• 2.4 GHz Wi-Fi up to 574 Mbps
• 5 GHz Wi-Fi up to 1200 Mbps
• 2 × Gigabit Ethernet ports
• 1 × Micro SIM slot
• 1 × miniPCI-e slot
• 802.3af/at PoE-in
• 12-57 V power input
• Maximum power consumption 13 W
• IP66 enclosure rating

Who it's for

• For system administrators
• For internet service providers
• For countryside property owners
• For remote locations
• For warehouse facilities
• For outdoor wireless deployments

Conclusion

The MikroTik wAP ax LTE7 kit combines LTE Category 7 connectivity, Wi-Fi 6, and an IP66-rated enclosure for reliable operation in demanding environments. It is suitable for mobile internet deployments, backup connectivity, and outdoor wireless infrastructure with advanced RouterOS functionality.
